SKU CNC 8070
Fagor CNC 8070 Control System
NewFagor
Control board for Fagor systems, part number CNC 8070. In the 8070 CNC system range. A new original-equipment unit, typically sourced in 3–7 days.
Call for price
Source to orderQuote-only line · priced per request once we confirm revision and stock
| Compatible systems | |
| Condition | New — factory sealed |
| Warranty | 90 days functional |
| Lead time | Source to order — 2–4 weeks, confirmed on quote |
| generation | 8070 (current) |
| hardware_manual | Ref. 2510 |
| compact_models | C70-10K (monitor+central unit+keyboard+operator panel); C70-10H/10HT/10V/10VT (touch on HT/VT; CAN operator panel connection) |
| modular_models | C70-15 (15" 1024x768, USB/CAN keyboard, CAN operator panel); C70-15AT (capacitive multi-touch, glove-optimized) |
| displays | 10.4" 800x600 18-bit (10K/10H/10V); 15" 1024x768 24-bit (15/15AT); MONITOR-LCD-10K-001 |
| handwheel_inputs | up to 3 handwheels MPG1-MPG3, 5 Vdc TTL A/B signals (LCD-10K model) |
| cad_series | Q7-A central units (10K/10V/10H/15") documented as CAD sets; Sercos and Mechatrolink variants |
| laser_variants | 8070 OL / BL / L ordering handbooks (OL current, BL discontinued) |
